autowalk length (max)
The rider's travel distance along the center of the longest continuous moving walkway installed in a structure.
The maximum autowalk length in a structure is the travel length of the longest continuous installed moving walkway that belongs to the structure. The length should be measured as the travel length of a rider on the center of the belt, even if the autowalk bends, rises, or deviates in any way from a straight line.
This is the value for a single installation, the largest in the object, and not a figure for the object as a whole. The others in the same building may be far smaller, so the value describes one unit and never an average.
Where the largest is replaced or removed, the value belongs to the next largest rather than staying with the one that is gone.
