framing system
The principal structural framework resisting gravity and lateral loads above ground, distinct from the foundation system.
Framing systems are forms of construction utilized to resist vertical forces (gravity) and lateral pressures (wind and earthquakes) against a building. The principal structural system of a building is its framing system; foundation systems are covered separately.
Framing systems carry and distribute the structural loads that occur above the surface of the earth. They consist of the columns, beams, and shear walls that support the structure. In some building systems, the floor slab is designed to assist in carrying the lateral loads of the building, thereby becoming an integral part of the framing system.
Most large steel frame buildings utilize corrugated steel deck that is topped with concrete as the floor system. Nearly all concrete frame buildings utilize cast in place concrete slabs for the floor system. Some steel frame buildings (a very few concrete frame buildings) utilize pre-cast concrete planks for the floor framing system. These planks are usually covered with a thin layer of concrete that is placed on the jobsite.
The appropriate and most economical framing system for a particular building is chosen by the structural engineer based on its height, usage type, local soil conditions, availability of materials, local building codes, local construction methods, and other factors.
framing system Photos
More specific definitions
12 sub-definitions-
bundled tube
A system in which multiple tube structures are clustered together for greater strength. -
buttressed core
A framing system with a strong central core reinforced by shear walls or other rigid elements radiating from it. -
core plus outrigger
A framing system in which a rigid core is tied to the perimeter with sturdy horizontal beams. -
framed tube
A system which resists lateral forces through a tightly interlocked perimeter frame. -
rigid frame
A framing system whose moment-resisting joints help the framework resist distortion. -
shear wall
A structural system using rigid vertical walls to resist distortion under lateral forces. -
shear wall plus frame
A system in which a strong slab wall acts in concert with strong joints to stabilize the frame. -
space truss
A three-dimensional truss with diagonal connections outside a single plane, used to resist lateral forces. -
superframe
A system in which multiple framed tubes are connected by horizontal framed trusses. -
trussed frame
A framework whose intersecting vertical and horizontal members are reinforced by one or more series of diagonal braces. -
trussed tube
A system in which the perimeter walls act as a rigid tube and are reinforced by vertical trusses. -
tube-in-tube
A system which combines an exceptionally strong perimeter frame with a similar tube at the core.
